Cheriton Victorian Antique Brass 1 gang 13A Double Pole Switched Socket Black/Black

Description

Width	88.5mm
Height	88.5mm
Depth	7.5mm
InsertType	1 gang 13A Double Pole Switched Socket
Insert_Finish	Black/Black
Uf_HAM_Plate_Range	Cheriton Victorian Box
PlateFinish	Cheriton Victorian Box Antique Brass
EAN_13_Barcode	5.02E+12
Dimensions_Nominal	Single: Height = 88.5mm Width = 88.5mm Depth = 7.5mm
Switched_Poles	Double
Current_Rating	13 Amp
Max_Load	13 Amp
Mains_Frequency	50Hz
Contact_Gap_Minimum	3mm
Terminal_Capacity_1	4×2.5mm²
Terminal_Capacity_2	3x4mm²
Terminal_Capacity_3	2x6mm² Multi-Strand
Terminal_Capacity_4	1x10mm²
Earth_Terminal_Capacity_1	4×2.5mm²
Earth_Terminal_Capacity_2	3x4mm²
Earth_Terminal_Capacity_3	2x6mm² Multi-Strand
Earth_Terminal_Capacity_4	1x10mm²
Product_Class1	Must be earthed
Ambient_Operating_Temp	-5° to +40°C
Recommended_Location	Internal Use Only
Max_Installation_Altitude	2000m
Standard_Approval	BS 1363-2
Additional_Notes	Dual Earth: Yes
Commodity_Code	85366990
Luckins_TSI	387387608
unit_weight	0
Uf_HAMInnerBoxQty	10
Uf_OuterBoxQty	100
Box_Fixing_Hole_Centres	60.3mm
Grid_Fixing_Hole_Centres	N/A
Uf_HAMPlateFinish	Antique Brass
Uf_HAMFrameFinish	n/a
WEB_InsertType	Switched Socket
WEB_NumberofGangs	1
MainInsertColour	Black
TrimColour	Black
Fixing_Hole_Centres	Box Fixing = 60.3mm Grid Fixing = N/A
Min_Wall_Box_Depth	35mm
IP_Rating	IP2XD
Plate_Finish	Antique Brass
WEB_Fixing	Visible
Voltage	220/250V AC
